Node for VidiU Go - 3G/4G/LTE Modem

3G / 4G / LTE modem
2 to 3 times the performance of carrier branded modems
Super durable and weather resistant aluminium Chassis
Compatible with VidiU Go

Node for VidiU Go is our cutting-edge, broadcast grade 4G / LTE modems that offer 2 to 3 times the performance of carrier-branded modems while fitting seamlessly to the sides of the VidiU Go chassis. With comprehensive data band support, Node can use any SIM card in regions around the world for cellular connectivity.

Exceptional cellular connectivity

Node offers superior cellular connectivity over off-the-shelf modems from major network carriers. With 2 to 3 times the performance of carrier branded modems, Node allows you to go live from locations with the poorest cellular connectivity.

Worldwide data band support

Node can operate on most 3G / 4G/ LTE data band for any region around the world.

Specifications
Dimensions: 78 x 31 x 36.2 mm
Weight: 91g
Construction: Machined aluminum
Mountability: Mounts to a VidiU Go using a USB connector secured with two thumb screws

Temperature:
Operating: -10ºC to 50ºC
Storage: -40ºC to 90ºC
Humidity:
Operating: 5% to 95% (non-condensing)
Storage: Max. 90%

Interface: 2 status LEDs - Power and Link
Interface: USB A Male

LTE: USA: LTE FDD Cat 4, Bands 2,4,5,13,17
Please see other models for Support in Other Regions
Umts: USA: HSDPA Cat 24, HSUPA Cat 6, Bands
850/1900
Please see other models for Support in Other Regions
Rf:
2x2 MIMO SMA
Band 17 (700 MHz), Band 13 (750 MHz) Band
5 (850 MHz)
Band 4 (1700 MHz) Band 2 (1900 MHz)
Power Class:
Class 3 23dBm LTE mode
Class 3 24 dBm for UMTS/HSDPA/HSUPA
mode
Data Rate:
LTE cat. 4: up to 150 Mb/s DL, 50 Mb/s UL
HSDPA cat.14, up to 21 Mb/s DL
HSUPA cat.6, up to 5.6 Mb/s UL
Sim: Full size SIM

Power Input: USB 2.0
Battery: None
Nominal Power Consumption: 5W Max

Ean code	9338716005349
Manufacturer item number	CINEURSANWFRSUR
Package Volume (l)	2.64
Package Weight (g)	800
Net weight (g)	720
Height (mm)	90
Width (mm)	115
Country of origin	China
Inner box quantity	1
Packaging Length/Depth (mm)	255
