BLACKMAGIC

BLACKMAGIC Teranex Mini IP Video 12G

Item number 60014285

Teranex Mini IP Video 12G
With the Blackmagic Teranex Mini now you can convert video to IP and route it over your existing ethernet network, or you can convert IP video back to SDI.

The Teranex Mini IP Video 12G uses standard Blackmagic Videohub software and hardware control panels to configure and switch IP video over ethernet as easily as SDI signals.

You get 12G-SDI and the low latency broadcast quality TICO codec so you can route HD over the built in gigabit ethernet connection or Ultra HD over 10G ethernet with an optional 10G SFP.

Included in box
1x Teranex Mini - IP Video 12G
1x SD card with software and manual

Technical data:
SDI Video Inputs  1 x 10-bit HD-SDI, 6G-SDI and 12G-SDI
SDI Video Outputs  2 x 10-bit HD-SDI, 6G-SDI and 12G-SDI
Ethernet  3G-SDI up to 1080p60 using TICO encoding/decoding
 Optional 10G optical data ethernet supporting Ultra HD
 up to 2160p60 using TICO encoding/decoding
Multi Rate Support  Auto detection of HD-SDI, 6G-SDI or 12G-SDI

Updates  USB 2.0 high speed (480Mb/s) interface or via Ethernet
Configuration  Ethernet or USB 2.0 for firmware updates and IP address setting
Reclocking  On all SDI outputs, auto switching between
 high definition, 6G-SDI or 12G-SDI video

Standards
HD Video Standards  720p50, 720p59.94, 720p60, 1080p23.98, 1080p24, 1080p25,
1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60,
1080PsF23.98, 1080PsF24, 1080i50, 1080i59.94, 1080i60
Automatic detection of Level A or Level B SDI on 1080p50, 1080p59.94 and 1080p60
2K Video Standards  2K DCI 23.98p, 2K DCI 24p, 2K DCI 25p, 2K DCI 23.98PsF, 2K DCI 24PsF, 2K DCI 25PsF
Ultra HD Video Standards  2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p50, 2160p59.94, 2160p60
4K Video Standards  4K DCI 23.98p ,4K DCI 24p, 4K DCI 25p, 4K DCI 29.97p, 4K DCI 30p
SDI Compliance  SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 310M,
SMPTE 425M, ITU-R BT.656 and ITU-R BT.601
SDI Video Rates  SDI video input is switchable between high definition,
ultra high definition and 4K. SDI switches between
1.5 Gb/s HD-SDI, 3G-SDI, 6G-SDI and 12G-SDI
SDI Video Sampling  4:2:2 plus 4:4:4 up to 4K DCI 30p
SDI Audio Sampling  Television standard sample rate of 48kHz and 24-bit
SDI Colour Precision  10-bit 4:2:2 and 4:4:4
SDI Colour Space  YUV or RGB for inputs, YUV for SDI outputs
SDI Auto Switching  Automatically selects between HD-SDI, 6G-SDI and 12G-SDI
SDI Metadata Support  Video payload identification ancillary data as per SMPTE 352M

Display  Optional Teranex Mini Smart Panel with 1.5 inch LCD for menu settings.

Software
Software Control  Blackmagic IP Video Setup and Videohub Router Control Software
included on SD card for Windows and Mac OS X
Internal Software Upgrade  Via included updater application.

Operating Systems  Mac OS X 10.11 El Capitan, macOS Sierra or later
Windows 8.1 or Windows 10

Settings Control
Control  Built in switches, setup software utility, or optional front mounted
Teranex Mini Smart Panel with LCD, rotary knob and six settings buttons

Power Requirements
Power Supply  IEC power cable required. 90 - 240V AC input
Power Fail Protection  Settings preserved and restored instantly at power on
Power over Ethernet  Can be powered via 48V DC using PoE+ (power over Ethernet)
Power Consumption  16 Watts
Dimensions  14 x 17 x 4.4 cm (5.5 x 6.6 x 1.7 inches)
Weight  0.58 kg (1.2 lbs)

Environmental Specifications
Operating Temperature  0° to 40° C (32° to 104° F)
Storage Temperature  -20° to 60° C (-4° to 140° F)
Relative Humidity  0% to 90% non-condensing

See more

Rec. price € 549,00

Ean code
9338716003901

Manufacturer item number
CONVNTRM/OB/IPV

Package Weight (g)
788

Net weight (g)
630.4

Country of origin
SG

Inner box quantity
1
