Teranex Mini - SDI Distribution 12G
Teranex Mini, the next generation 12G-SDI converters with award winning Teranex quality and support for all SD, HD and Ultra HD formats up to 2160p60. All Teranex Minis include an internal AC power supply, professional XLR analog and AES/EBU audio connections and an ethernet connection for remote management and PoE alternate power. Teranex Mini features a user upgradable front panel that includes a colour display and user controls so you can quickly monitor video and change settings right from the front of the converter. You get all of the same great features of regular mini converters and so much more.
Distribute a single SDI video input to up to eight SDI outputs. Features the latest multi rate 12G-SDI connections with full SDI re-clocking allowing the converter to automatically switch between all SD, HD and Ultra HD formats up to 2160p60. Perfect for distributing a single SDI signal...
Included in box
1 x Teranex Mini - SDI Distribution 12G
1 x Software SD Card
Technical data:
SDI Video Input 1 x 12G-SDI SD/HD/2K/4K auto switching.
SDI Video Output 8 x 12G-SDI automatically matches the SD/HD/2K/4K 12G-SDI input
Multi Rate Support Automatic switching between SD/HD/2K and 4K
Updates and Configuration USB or Ethernet
Re-Clocking Yes
Standards
SD Format Support 525/29.97 NTSC, 625/25 PAL
HD Format Support 720p50, 720p59.94, 720p60, 1080i50, 1080i59.94, 1080i60, 1080PsF23.98, 1080PsF24, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60.
2K Format Support 1080PsF23.98, 1080PsF24, 1080PsF25, 1080p23.98, 1080p24, 1080p25,
Ultra HD Format Support 2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p50, 2160p60.
4K Format Support 2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30.
SDI Compliance SMPTE 259M, 292M, 296M, 372M, 425M, ST 2081 & ST 2082
SDI Video Rates SDI video connections are switchable between standard definition, high definition level B 3G-SDI, 6G-SDI and 12G-SDI.
SDI Video Sampling 4:2:2 and 4:4:4
SDI Audio Sampling Television standard sample rate of 48 kHz and 24-bit.
SDI Colour Space YUV & RGB
Software
Software Control Mac OS X™ and Windows™ software upgrade via USB and Ethernet.
Internal Software Upgrade Via included updater application.
Settings Control
Basic Settings Control Mini Switches, USB and Ethernet via free software utility.
Optional Front Panel Control Front mounted Smart Panel with LCD, rotary knob and six settings buttons.
Power Requirements
Power Supply 1 x built-in international AC power supply with IEC C14 inlet. IEC Power cable required. 90 - 240V AC Input.
Power Over Ethernet Can be powered via 48V DC using PoE+ (power over ethernet).
Power Consumption 18 Watts
Operational Voltage Range 90 - 240V AC
Physical Specifications 140mm x 44mm x 170mm
Weight 580g
Environmental Specifications
Operating Temperature 0°to 40°C (32° to 104°F)
Storage Temperature -20°to 60°C (-4° to 140°F)
Relative Humidity 0% to 90% non-condensing
