BLACKMAGIC

BLACKMAGIC Mini Converter Sync Generator

Item number 60014271

Sync Generator
• Mini Converter Series
• Six Output
• Tri-Sync or Black Burst

The Blackmagic Design CONVMSYNC is a sync generator. This generator will generate a reference signal in either high definition or standard definition parmeters. It is part of the Mini Converter series and offers six BNC outputs.

Space Saving
Broadcast Converter models are extremely compact, so you can install in the front or rear side of equipment racks, saving valuable equipment space.

Security
This device features a handy cable tie point to lock the power down tight and prevent your power being disconnected.

Formats
Many video standards are supported including, NTSC, PAL, 1080i/59.94, 1080i/50, 1080psf/23.98, 1080psf/24, 720p/59.94 and 720p/50 formats, plus new formats can be added via USB.

HD or SD
Tri-level high definition or standard definition black burst can be selected for the matching video format needed.

Technical specifications:
Output:
Reference Output x6, Analog Black Burst or Tri-Level Sync, on BNC connectors

Input:
None

Television System:
625/25 PAL
525/29.97 NTSC
1080PsF23.98
1080PsF24
1080i50
1080i59.94
720p50
720p59.94
Selectable

Control:
Dip Switch Format Selection

Power Source:
12VDC on an AC Power Adapter

See more

Rec. price € 251,01

Ean code
9338716000443

Manufacturer item number
CONVMSYNC

Package Weight (g)
500

Net weight (g)
400

Country of origin
SG

Inner box quantity
1
