BLACKMAGIC

BLACKMAGIC Mini Converter Optical Fiber 12G

Item number 60014267

Mini Converter Optical Fiber 12G-SDI
• Converts 12G/6G/3G-SDI to Optical Fiber
• Supports Signals up to DCI 4K25
• Multi-Rate, Bidirectional Capability
• Requires Separate SFP Optical Module

The Mini Converter Optical Fiber 12G-SDI from Blackmagic Design offers bidirectional, multi-rate SDI to optical fiber conversion capabilities with complete independence in each direction and support for up to DCI 4K25 and UHD 4K60 signals. This converter has one SFP optical fiber socket (requires a separate module), one 12G/HD/SD-SDI input, and one 12G/HD/SD-SDI output. With a 10-bit rate, you can take advantage of long fiber runs and compatibility with both studio and field HD-SDI and SD equipment.

Features include automatic signal detection and support for up to 16-channel embedded audio. Settings can be easily changed using the diagrammed function switches, or via the macOS/Windows-compatible converter software. This compact converter features a sturdy metal housing and includes a 12V universal power supply with a locking connection for added security.

Technical data:

Input
Video Input Connectors 1 x BNC (12G-SDI)
Input Video Format SDI (4:4:4/4:2:2 RGB, YUV)
DCI 4K: 23.98/24/25 fps
UHD 4K: 23.98/24/25/29.97/30/50/59.94/60 fps
DCI 2K: 23.98/24/25 fps
DCI 2KPsF: 23.98/24/25 fps
1080p: 23.98/24/25/29.97/30/50/59.94/60 fps
1080PsF: 23.98/24/25/29.97/30 fps
1080i: 50/59.94/60 fps
Embedded Audio Input SDI: 16-Channel

Output
Video Output Connectors 1 x BNC (12G-SDI / 3G-SDI / 6G-SDI)
Output Video Format SDI (10-Bit 4:4:4/4:2:2 RGB, YUV)
DCI 4K: 23.98/24/25 fps
UHD 4K: 23.98/24/25/29.97/30/50/59.94/60 fps
DCI 2K: 23.98/24/25 fps
DCI 2KPsF: 23.98/24/25 fps
1080p: 23.98/24/25/29.97/30/50/59.94/60 fps
1080PsF: 23.98/24/25/29.97/30 fps
1080i: 50/59.94/60 fps
Embedded Audio Output SDI: 16-Channel

Standards
Video Standard Compliance SMPTE 259M/292M/296M/297M/424M-B/425M/ST-2081
ITU -R BT.601
HDCP Support None

Connectivity
Expansion Slots 1 x SFP Slot

Power
Power Connector 1 x Barrel (6 to 36 VDC) Input
Power Consumption Power Supply: 2 W

Environmental
Operating Temperature 32 to 104°F / 0 to 40°C
Storage Temperature -4 to 113°F / -20 to 45°C
Operating Humidity 0 to 90%

General
Dimensions 4.33 x 2.32 x 0.9" / 109.98 x 58.93 x 22.86 mm
Weight 7.4 oz / 210 g

See more

Rec. price € 200,61

Ean code
9338716005400

Manufacturer item number
CONVMOF12G

Package Volume (l)
1.18

Package Weight (g)
451

Net weight (g)
360.8

Height (mm)
140

Width (mm)
120

Country of origin
SG

Inner box quantity
1

Packaging Length/Depth (mm)
70
