BLACKMAGIC

BLACKMAGIC Mini Converter Audio to SDI 4K

Item number 60014264

Mini Converter Audio to SDI 4K
The mini Converter Audio to SDI 4K includes everything you need to embed 4 channels of analog audio or 8 channels of AES/EBU digital audio into any SDI video connection. Now you can embed professional audio from devices such as audio mixers and analog decks into SDI video connections for use with SDI routers and decks or to add extra audio channels to video converters!.

The new Blackmagic Mini Converter range are the worlds most advanced converters because they include the latest 6G-SDI technology, plus automatically detect the input video format and instantly change between virtually all SD, HD and Ultra HD video standards! Simply plug in and Mini Converters will convert between your equipment all automatically!

Included in box
Mini Converter Audio to SDI 4K
12V universal power supply with international socket adapters

Technical data:
Connections
SDI Video Input Switchable between SD, HD, 3G and 6G-SDI.
SDI Video Output Automatically matches the SD, HD, 3G and 6G-SDI video input.
Analog Audio 4 channels of professional balanced analog audio with standard 1/4 inch jack connections.
AES/EBU Digital Audio 8 channels of professional balanced digital with standard 1/4 inch jack connections.
SDI Redundant Input Automatically switches over if main SDI input is lost.
Multi Rate Support Auto detection of 4K, UHD, 2K, HD or SD SDI inputs.
Updates and Configuration USB
Reclocking Yes

Standards
SDI Compliance SMPTE 292M, SMPTE 259M, SMPTE 296M, SMPTE 372M, SMPTE 425M, ITU-R BT.656 and ITU-R BT.601, SMPTE ST-2036
SDI Video Rates SDI video connections are switchable between standard definition and high definition.
SDI Video Sampling 4:2:2, 4:4:4
SDI Audio Sampling Television standard sample rate of 48 kHz and 24 bit.
SDI Color Precision 4:2:2, 4:4:4
SDI Color Space YUV, RGB
SDI Auto Switching Automatically selects between SD, HD, 3G and 6G-SDI.

SDI Format Support
525/29.97 NTSC
525/23.98 NTSC
625/25 PAL
720p50
720p59.94
720p60
1080i50
1080i59.94
1080i60
1080p23.98
1080PsF23.98
1080p24
1080PsF24
1080p25
1080PsF25
1080p29.97
1080PsF29.97
1080p30
1080PsF30
1080p50
1080p60
2048x1080p23.98
2048x1080p24
2048x1080p25
2048x1080PsF23.98
2048x1080PsF24
2048x1080PsF25
3840x2160p23.98
3840x2160p24
3840x2160p25
3840x2160p29.97
3840x2160p30
4096x2160p23.98
4096x2160p24
4096x2160p25
4096x2160p29.97
4096x2160p30

Software
Software Control Mac OS X™ and Windows™ software upgrade via USB.
Internal Software Upgrade Via included updater application.
Settings Control Mini Switches or USB software.

Power Requirements
Power Supply +12V universal power supply included with international socket adapters for all countries. Cable tie point.
Power Consumption 8.40 Watts
Operational Voltage Range 12V - 31V DC

Physical Specifications Length 115mm x Width 92.27mm x Height 23mm
Weight 216g

Environmental Specifications
Operating temperature 0° to 40° C (32° to 104° F)
Storage temperature -20° to 60° C (-4° to 113° F)
Relative Humidity 0% to 90% non-condensing

See more

Rec. price € 351,82

Ean code
9338716002775

Manufacturer item number
CONVMCAUDS4K

Package Weight (g)
541

Net weight (g)
432.8

Country of origin
SG

Inner box quantity
1
