BLACKMAGIC

BLACKMAGIC Mini Converter Audio to SDI 2

Item number 60014263

Audio to SDI Mini Converter
• Embed Audio into up to 1080p SDI Signals
• Four 1/4" Audio Input Jacks
• Supports 4 Channels of Analog Audio
• Supports 8 Channels of AES/EBU Audio

Embed audio into 3G/HD/SD-SDI sources in up to 1080p60 resolution with the Audio to SDI Mini Converter from Blackmagic Design. Connect up to four channels of balanced analog or eight channels of AES/EBU audio via four 1/4" jacks.

In addition to a dedicated SDI input, the converter also features a redundant SDI input that allows you to run a backup cable in case the first is lost. This is useful in mission-critical applications, especially outdoors or in crowded venues where there is a higher chance of damage to the cable.

Technical data:
SDI Input 1 x SDI on BNC (switchable between 3G/HD/SD)
1 x 3G/HD/SD-SDI redundant input (automatically switches over if main SDI input is lost)
Audio Input 4 x 1/4" jacks support 4 channels of balanced analog, or 8 channels of balanced AES/EBU digital audio
SDI Output 1 x SDI on BNC (switchable between 3G/HD/SD)
SDI Auto Switching Auto-detection of 3G/2K/HD/SD-SDI
Updates and Configuration Via USB 2.0 high-speed (480 Mb/s)
Reclocking Yes
SDI Compliance SMPTE 292M/259M/296M/372M/424M-B/425M
ITU-R BT.656/BT.601
SDI Video Rates SDI video connections are switchable between HD and SD
SDI Video Sampling 4:2:2, 4:4:4
SDI Audio Sampling Television standard sample rate of 48 kHz and 24-bit
SDI Color Precision 4:2:2, 4:4:4
SDI Color Space YUV, RGB
SDI Auto Switching Automatically selects between 3G/HD/SD
SDI Format Support 1080p: 60/59.94/50/30/29.97/25/24/23.98
1080PsF: 30/29.97/25/24/23.98
1080i: 60/59.94/50
720p: 60/59.94/50
525i: 59.94 NTSC
625i: 50 PAL
2K Format Support 2K DCI 25p/24p/23.98p
2K DCI 25PsF/24PsF/23.98PsF
Software Control Mac OS X and Windows software upgrade via USB
Internal Software Upgrade Via included updater application
Operating System Mac OS X 10.11 El Capitan, macOS Sierra or later
Windows 8.1 or Windows 10
Settings Control Mini switches or USB software
Power Supply +12 V universal power supply included, with international socket adapters for all countries and cable tie point
Power Consumption 8.4 W
Operational Voltage Range 12 VDC
Operating Temperature 32 to 104°F / 0 to 40°C
Storage Temperature -4 to 113°F / -20 to 45°C
Relative Humidity 0 to 90% non-condensing
Dimensions 4.5 x 3.6 x 0.9" / 11.5 x 9.2 x 2.3 cm
Weight 7.6 oz / 215 g

See more

Rec. price € 251,01

Ean code
9338716004571

Manufacturer item number
CONVMCAUDS2

Package Volume (l)
1.17

Package Weight (g)
480

Net weight (g)
384

Height (mm)
150

Width (mm)
130

Country of origin
SG

Inner box quantity
1

Packaging Length/Depth (mm)
60
