BLACKMAGIC

BLACKMAGIC Mini Converter SDI to HDMI 6G

Item number 60014261

SDI to HDMI 6G Mini Converter
• 2 x 4K SDI Input
• 1 x HDMI Type A and 1 x SDI Output
• Supports SD, HD, UHD 4K & DCI 4K Signals
• Automatic Input Signal Detection

The Blackmagic Design SDI to HDMI 6G Mini Converter converts SDI in resolutions up to DCI 4K (4096 x 2160) at 24p and UHD 4K (3840 x 2160) up to 60p to HDMI. This is useful for connecting consumer devices that require HDMI signals with professional SDI video equipment. With a compact form factor and easy-to-use controls, the Mini Converter is
ideal for a variety of broadcast, post production, and professional AV applications.

Using 4K HDMI and 6G-SDI technologies, the Mini Converter automatically detects the input video format and instantly changes between SD, HD, and UHD/DCI 4K formats. Featuring two SDI inputs, and both an SDI and HDMI output, the unit will automatically switch from the main SDI input to the alternate input if the main input fails. Audio is de-embedded from the SDI input and available in the HDMI output as well as the AES/EBU or analog audio output.

• The Mini Converter's settings are controlled using the built-in switches or via USB using the control software for Max OS X or Windows computers, which can be downloaded on Blackmagic Design's website. The USB port also enables the firmware to be updated.
• The device is powered by an included 12V power supply and includes international socket adapters.

Additional Features
• 4:2:2 Sampling and color precision
• HD scaler and SD down-conversion
• 24-bit, 48 kHz audio sampling
• Compliant with SMPTE 259M, 292M, 296M, 372M, 424M, 425M Level A/B, and SMPTE ST-2081 standards
• Down-conversion for monitoring Ultra HD on HD monitors
• Built-in 3D LUTs
• HDMI instant lock for instant video display when an SDI input is connected

Technical specifications:
Video Input 2 x 6G-SDI
Video Output 1 x HDMI type A
1 x 6G-SDI
Multi-Rate Support Auto detection of SD, HD, or 4K signals
Reclocking Yes
Audio Output Analog: 2 channels with 1 x 1/4" jack per channel
AES/EBU: 4 channels with 1 x 1/4" jack
Format Support DCI 4K
24p

UHD 4K
3840 x 2160p: 30/29.97/25/24/23.98

HD
1080p: 60/59.94/50/30/29.97/25/24/23.98
1080i: 60/59.94/50
720p: 60/59.94/50

SD
NTSC: 525i/59.94
PAL: 625i/50

SDI Compliance SMPTE 259M/292M/296M/372M/424M/425M Level A or Level B/SMPTE ST-2081
SDI Video Rates SDI video connections are switchable between standard definition, high definition, Level A or Level B 3G-SDI and 6G-SDI.
SDI Video Sampling 4:2:2
4:4:4
SDI Color Precision 4:2:2
4:4:4
SDI Color Space YUV
RGB
SDI Audio Sampling 24-bit, 48 kHz
SDI Auto Switching Automatically detects SD, HD, or 6G-SDI
HDMI Format Support UHD 4K
3840 x 2160p: 30/29.97/25/24/23.98

HD
1080p: 60/59.94/50/30/29.97/25/24/23.98
1080i: 60/59.94/50
720p: 60/59.94/50

SD
NTSC: 525i/59.94
PAL: 625i/50
HDMI Color Space YUV and RGB
HDMI Color Precision 4:2:2
4:4:4
Format Conversion HD down-conversion
Settings Control Mini switches or USB software
Firmware Upgradeable Via USB
Power Supply 12 VDC
Power Consumption 5.2 W
Operational Voltage Range 12 to 31 VDC
Operating Temperature 32 to 104°F / 0 to 40 °C
Storage Temperature -4 to 113°F / -20 to 45 °C
Relative Humidity 0 to 90% non-condensing
Dimensions 4.49 x 3.63 x 0.90" / 11.40 x 9.22 x 2.29 cm
Weight 9.06 oz / 256.85 g

See more

Rec. price € 251,01

Ean code
9338716005172

Manufacturer item number
CONVMBSH4K6G

Package Volume (l)
1.32

Package Weight (g)
540

Net weight (g)
486

Height (mm)
65

Width (mm)
140

Country of origin
SG

Inner box quantity
1

Packaging Length/Depth (mm)
145
