BLACKMAGIC

BLACKMAGIC Mini Converter Analog to SDI 2

Item number 60014257

Mini Converter Analog to SDI
• Analog to SDI Conversion
• Embedded Audio

The Mini Converter Analog to SDI from Blackmagic will accept an HD/SD component, NTSC, PAL, or S-video signal and convert it to an SDI output. You can also choose to embed SDI audio from balanced AES/EBU or analog audio inputs. Use this device to convert video from Betacam SP, VHS, set-top boxes, HDV cameras, and other similar devices.

Analog to SDI Conversion
Use this device to convert analog video sources to SDI video output.

Embedded Audio
This unit can embed SDI audio from balanced AES/EBU or analog audio inputs.

Technical specifications:
Input:
(1) component, NTSC, PAL, and S-video via 3x BNCs

Output:
(2) SDI (switchable between SD, HD & 3Gbs SDI)

Audio Analog:
(2) channels of professional balanced analog with standard 1/4" jack connections
Digital:
(2) channels of professional balanced digital with standard 1/4" jack connections, AES/EBU standard
(Audio inputs are shared)

Power 12VDC

See more

Rec. price € 251,01

Ean code
9338716001341

Manufacturer item number
CONVMAAS2

Package Volume (l)
1.18

Package Weight (g)
510

Net weight (g)
459

Height (mm)
140

Width (mm)
140

Country of origin
SG

Inner box quantity
1

Packaging Length/Depth (mm)
60
