TRIAX Network cable CAT6 UTP PE 100m Black

23 AWG solid copper inner conductors provide high conductivity and corrosion resistance
Suitable for PoE (Power over Ethernet)
Fire rated: Fca, suitable for all outdoor installations
The central pair separator maintains performance and geometry
Max. bandwidth: 250 MHz
Impedance: 100 Ohm
Cable type: Round cable
Packing: 100 m drum
Length marked every meter
Complies with all CAT6 standards
CE, RoHS compliant

Unshielded CAT 6 network cable that can handle bandwidth up to 250 MHz (1000 BASE-T Ethernet) and 1000 mbps speed (short length up to 10 Gbit).

Solid inner copper conductor allows the cable to carry Ethernet data signal over distance (with less attenuation) and more durable for a longer period.

The central pair separator improves the transmission speeds by further balancing the cable pair structure.

Specifications
CONSTRUCTION
Introduces material Cu
Introduces dimension 0.53 ± 0.005 mm
Dielectric Material Solid PE
Dielectric Dimension 1.00 ± 0.05 mm
Flat filler Material PE Spline
Outer casing - material PE
Outer casing - dimension 6.0 ± 0.50 mm
Color code - pair 1 Blue / White-Blue
Color code - pair 2 Orange / White-Orange
Color code - pair 3 Green / White-Green
Color code - pair 4 Brown / White-Brown
NEXT
Next 1 MHz 74.30 dB
Next 4 MHz 65.30 dB
Next 10 MHz 59.30 dB
Next 16 MHz 56.20 dB
Next 25 MHz 53.30 dB
Next 3125 MHz 51.90 dB
Next 100 MHz 44.30 dB
Next 200 MHz 39.80 dB
Next 250 MHz 38.30 dB
CHARACTERISTICS
Type CAT 6 PE
LOSS
Attenuation (20 ° C / 100mtr) @ 1 Mhz 2.00 dB
Attenuation (20 ° C / 100mtr) @ 4 MHz 3.80 dB
Attenuation (20 ° C / 100mtr) @ 10 Mhz 6.00 dB
Attenuation (20 ° C / 100mtr) @ 16 Mhz 7.60 dB
Attenuation (20 ° C / 100mtr) @ 25 Mhz 9.50 dB
Attenuation (20 ° C / 100mtr) @ 31.25 MHz 10.70 dB
Attenuation (20 ° C / 100mtr) @ 100 Mhz 19.80 dB
Attenuation (20 ° C / 100mtr) @ 200 Mhz 29.00 dB
Attenuation (20 ° C / 100mtr) @ 250 Mhz 32.80 dB
REFLECTION DAMPING
Return loss @ 1 MHz 20.00 dB
Return loss @ 4 MHz 23.00 dB
Return loss @ 10 MHz 25.00 dB
Return loss @ 16 MHz 25.00 dB
Return loss @ 25 MHz 24.30 dB
Return loss @ 31.25 MHz 23.60 dB
Return loss @ 100 MHz 20.10 dB
Return loss @ 200 MHz 18.00 dB
Return loss @ 200 MHz 17.30 dB
ELECTRICAL DATA
Characteristic Impedance 1100MHz 100 ± 15 Ω
Characteristic Impedance 100-250MHz 100 ± 20 Ω
Conductor DC resistance 20 gr. C <95 Ohm / km
Mutual capacity 1 KHz <1500 pF / m
GENERAL SPECIFICATIONS
Use Outdoors
Fire class EN 50575 (Fca)
DoP number TR0083
MECHANICAL DATA
Cable length 100 m
Minimum bending radius single repeated 8xD mm
Colour: Black
Total height 0.117 m
Total width 0.300 m
Total depth 0.300 m
Unit volume 0.011 m3
Net weight 3,300 kg
Tar weight 0.700 kg
Total weight 4,000 kg
