Tilta Nucleus-M Wireless Lens Control System Partial Kit II (Right Handgrip)
• Customizable focus, iris, and zoom control
• Run/stop control for select cameras
• ARRI-style rosette mounting and optional gimbal adapter mounts
• 1000' wireless control range
• 85, 180, and 310° knob rotation settings
• LCD display and LED indicators

The Tilta right-side Wireless Handgrip provides fingertip lens control while also functioning as a handgrip support for your camera rig. This component of the separately available Nucleus-M FIZ (focus/iris/zoom) system enables you to split control between the handgrip and the hand unit as you prefer.

With a wireless control range of up to 1000', the Wireless Handgrip can be used for drone or car-mounted shots in addition to handheld configurations. Mount the handgrip using its ARRI-style rosette or use an optional adapter to mount to your gimbal. Use this grip with a separately available left-side grip for full focus, iris, and zoom control of cine-style lenses.

Handgrip features include three knob-rotation settings, optional adapters for either bar- or ring-based gimbals, LED indicators, and an LCD display. Powered by two 18650 lithium-ion batteries (not included), the handgrips can maintain a single charge for up to two days. As part of the Nucleus-M system, the Wireless Handgrip provides a run/stop function for select cameras.

Specifications:
Current 0.1 A
Voltage Battery: 7.2 V
External: 7.2-14.8 V
Port Power/Communication: 4-pin
Rotation 85, 180, 310°
Battery Type 18650
Operating Frequency 2.4 GHz
Emission Power 10-100 MW
Maximum Transmission Distance 33-328' / 10-100 m
Operating Temperature Range -4 to 122°F / -20 to 50°C
Material of Construction Aluminum alloy, stainless steel
ABS plastic, rubber
Dimensions With Thumb Unit: 6.9 x 3.3 x 2.3" / 17.6 x 8.5 x 6. cm
Without Thumb Unit: 6.9 x 3.3 x 1.2" / 17.6 x 8.5 x 3.1 cm
Weight With Thumb Unit: 12.5 oz / 355 g
Without Thumb Unit: 12 oz / 340 g
